General Information:

Production Dates: 2022-Current
MSRP: $49.99 (Suggested retail price. Subject to change without notice.)
Model Number Breakdown: "MS" Manual Sprayer, "2310" The first two numbers are the tank gallon capacity. The last two numbers are the sub-version with that model series
Replaced Model: MS-21H
Replaced By Model: N/A
Uses & Applications: Designed for multiple uses including both indoor and outdoor applications for weed and insect control, feeding and watering plants, cleaning, sanitizing and applying harsh chemicals
Box Dimensions: Length: 9 in. Width: 9 in. Height: 25 in. Weight: 7 lb.
Operator's/Safety Manuals, Parts Catalogs: In Business Portal, go to the "Search" tab and enter the model number in the "Item #" field. From there, select the correct document.
Accessories: In the Knowledge Base, search the accessory name (for example, "wand") and view the related article to confirm compatibility with this model.

Features:

2-gallon tank with wide mouth opening for easy filling and cleaning
High-capacity, professional-grade pump
Professional-grade fiberglass wand
Includes adjustable, flat fan, hollow cone and jet stream nozzles
Lockable shut-off to reduce hand fatigue
Easy-to-clean, in-line filtration system
Multiple nozzles included for ultimate versatility
Accessory shoulder strap available

Technical Specifications: There is no Service Data for this model. For more details on specifications, torque limits, service limits, and special tools, reach out to the Product Manager. Please copy Kristina Fink so any information obtained can be added to the Knowledgebase.

Length: 14.7 in.
Width: 8.6 in.
Height: 20 in.
Weight: 5 lb.
Max Tank Capacity: 2.3 Gallons
Max Pressure Rating: 45 PSI
Tank Mouth Opening: 4.5"
Pump Type: Piston
Hose Length: 51 in.
Base Material: High-density polyethylene
Wand Material: Fiberglass
Nozzle Type: ADJ, Flat 80 Degree Fan, Cone and Stream
Wand Length: 20.5 in.
Tank Material: HDPE
Flow Control Valve: Commercial grade with comfort grip
Seal Material Type: Chemical resistant FPM
Filtration System: In-line filter in shut-off handle
