ES-250

General Information:

• Production Dates: 2011-Current
• MSRP: $249.99 (Suggested retail price. Subject to change without notice.)
• Model Number Breakdown: "ES" Engine Shredder, "250" The first two numbers are the engine cc size generally within, plus or minus 1 cc to 2 cc. The last number is the sub-version within that model series
• Replaced Model: ES-210
• Replaced By Model: N/A
• Uses & Applications: Designed to clean up and shred leaves, grass clippings, dust
• Box Dimensions: Length: 37 in. Width: 17 in. Height: 12 in. Weight: 19 lb.
• Operator's/Safety Manuals, Parts Catalogs: In Business Portal, go to the "Search" tab and enter the model number in the "Item #" field. From there, select the correct document.

Features:

• 25.4 profession-grade engine for outstanding performance and durability
• Patented 4-blade shredding mechanism reduces debris by a ratio of 12:1
• Large, 2-bushel collection bag with rear zipper makes for convenient emptying
• Exclusive curved blower tube provides rotational control to reduce user fatigue (when set up as a blower)
• Positive locking collar secures blower pipe to unit
• 35 in. long intake tube for easy, no-stopping debris pick up
• 392 CFM and 165 MPH blowing performance increases productivity

Technical Specifications: For more details on specifications, torque limits, service limits, and special tools, refer to the attached "Service Data."

• Length: 13 in.
• Width: 11 in.
• Height: 13.6 in.
• Weight: 9.5 lb.
• Engine Type: Air cooled, two-stroke, single cylinder gasoline engine
• Engine Displacement: 25.4 cc
• Bore: 1.34 in.
• Stroke: 1.10 in.
• Compression Ratio: 7.0

• Ignition Type: CDI (Capacitor discharge ignition)
• Spark Plug: NGK BPM-8Y

• Starter: Automatic recoil starter
• Fuel Tank Capacity: 15.9 fl. oz.
• Exhaust: Spark arrestor muffler
• Air Volume: 392 CFM
• Maximum Air Speed: 165 MPH
• Idle Speed: 3,000 RPM
• Wide Open Throttle Speed: 7,100 RPM
• Compression Pressure: 122 PSI
• Primary Coil Resistance: 300-340 ohms
• Secondary Coil Resistance: 2.5-3.0 ohms
