BRD-280

Modified on Wed, Nov 12, 2025 at 8:59 AM

General Information:

Production Dates: 2009-2017
MSRP: $539.99 (Suggested retail price. Subject to change without notice)
Model Number Breakdown: "BRD" Bed Redefiner, "280" The first two numbers are the engine cc size generally within, plus or minus 1 cc to 2 cc. The last number is the sub-version within that model series
Replaced Model: N/A
Replaced By Model: BRD-2620
Uses & Applications: Designed to create an edge along flower and mulch beds
Box Dimensions: Length: 73 in. Width: 13 in. Height: 12 in. Weight: 26 lb.
Operator's/Safety Manuals, Parts Catalogs: In Business Portal, go to the "Search" tab and enter the model number in the "Item #" field. From there, select the correct document
Accessories: No accessories available for this model

Features:

28.1 cc Power Boost Vortex engine
Unique, six finger blade geometry
Rubber throttle control handle
59" straight shaft with flex cable drive
Over-sized high impact nylon shield with guide marker
Large, adjustable support wheel
21.6 fl. oz capacity see through fuel tank

Technical Specifications: For more details on specifications, torque limits, service limits, and special tools, refer to the attached "Service Data."

Length: 70.7 in.
Width: 11.9 in.
Height: 12.9 in.
Weight: 17.7 lb.
Engine Type: Air cooled, two-stroke, single cylinder gasoline engine
Engine Displacement: 25.4 cc
Bore: 1.339 in.
Stroke: 1.102 in.
Compression Ratio: 7.6
Ignition Type: CDI (Capacitor discharge ignition)
Spark Plug: NGK CMR-7H
Starter: Automatic rewind
Fuel Tank Capacity: 17.9 fl. oz.
Exhaust: Spark arrestor muffler
Clutch: Centrifugal
Drive Shaft: Flexible
Gear Case Ratio: 2.07
Idle Speed: 2,900 RPM
Wide Open Throttle Speed: 10,700 RPM
Compression Pressure: 7.6
Primary Coil Resistance: N/A (This model does not have a primary coil resistance because it uses a special spark advance system. Therefore, no primary resistance readings are available for this unit.)
Secondary Coil Resistance: 780-1180 ohms

Attachments (1)

pdf

BRD-280 Service Data.pdf
208 KB
